FPL9232 - Raphael Leisure Building 800x800

FPL9232 - Raphael Leisure Building 800x800

800x800 Two-storey Leisure Building

  • wall thickness: 94mm
  • wall outside dimension: 800 x 800cm (W/D)
  • roof overhang: F/B = 100cm, L/R =60 cm
  • side wall height: 286cm, ridge height: 600cm
  • roof area: 114m², slope: 36 degrees
  • ground floor doors: 1x 98 x 210cm 1/2 glazed, 2x 76 x 201cm internal, 1x 88.5 x 201cm internal
  • ground floor windows: 1x 98 x 112cm tilt/turn, 5x 140 x 112cm tilt/turn
  • upper floor doors: 2x 76 x 201cm internal
  • upper floor windows: 4x 75 x 98cm tilt/turn
  • living area: approx. 105m²
  • wall area: 130m²


Please note that you can add or change doors and windows to personalise your building. Some pictures may show buildings with non-standard features, such as extra windows, added to the standard configuration. Please check the full description or call us for further information.
