FPL9525 - MH2 3030 S100 AN 120 SD
3.00m x 4.10m panel building with 2 rooms
- wall thickness: 19mm
- wall outside dimension: 300 x 410cm (W/D)
- side wall height: 224cm, ridge height: 263cm
- roof overhang: F/R/B= 25cm, L= 130cm
- roof area: 21.5m², slope: 15 degrees
- double door 132 x 203.6cm extensively glazed
- window: 60 x 60cm turn cant, 100 x 40cm tilt, 2x 50 x 203.6cm fixed
- BHB gutter sets
- ventilation grille
- rain barrel
All our Bertsch Holzbau log cabins and summerhouses are constructed using premium quality, Scandinavian sourced wood. They are usually available in a variety of wall thicknesses and they are among the best buildings of this sort available anywhere. This level of quality is backed up by a company that has over 20 years experience in supplying quality timber buildings.
Whether it is to be used as a summerhouse, entertainment cabin, home office, extra bedroom or just a quiet place in the garden, you will find our buildings very hard to beat.
Some of the features included in our buildings are...
- *Double conical tongue and groove special profiles to ensure higher stability.
- Tongue and groove wind-lock system which helps increase protection from the elements.
- Easy DIY assembly.
- Fully treated foundation supports beams.
- Purlin heads at the gable ends have 19mm shielding facings to protect them.
- *Roof supports are a minimum of 80mm x 160mm purlins and 19mm tongue and groove roof boards.
- Choice of 5 different colours of roof tiles to choose from.
- *Internal floors are 22mm tongue and groove boards.
- *All windows and doors are double glazed and are fitted with weather strips
- Choice of either plain window or georgian bars.
- All windows can be fixed or have a German branded, tilt and open mechanism
- Door and window hardware include high quality polished aluminium handles.
- Choice of either straight or waved facia boards.
- Option to fit roof and floor insulation
* Generally this applies to 45mm or thicker walls. Purlin sizes will go thicker as building size increases.
